Quickstart

This walk-through covers the things you'll do in your first session with sadda: create a project, register a recording as a bundle, run pitch and formants, and query the results.

Install

pip install sadda           # core
pip install "sadda[ml]"     # adds onnxruntime — needed for VAD + embeddings

Create a project

A project is a directory containing audio, derived signals, annotations, and a SQLite-backed corpus database. Create one:

import sadda
from pathlib import Path

proj = sadda.new_project(Path("vowels"), name="vowel-study")

The directory vowels/ now contains:

vowels/
├── corpus.db              # SQLite — bundles, tiers, annotations, provenance
├── project.toml           # Project metadata
├── signals/
│   ├── original/          # Source audio (copied at registration)
│   ├── derived/           # Parquet sidecars for dense tiers
│   └── .in_progress/      # Live-recording staging
├── attachments/
├── exports/
└── recipes/               # Auto-generated reproducibility scripts

Register a bundle

A bundle is one recording with its metadata. Registering it copies the WAV into signals/original/ and inserts a bundle row:

bundle_id = proj.add_bundle("speaker_01_take_1", Path("rec01.wav"))

You can also attach a JSON extra payload, and link the bundle to a Speaker or Session (created via proj.add_speaker(...) / proj.add_session(...)) by passing their ids:

speaker_id = proj.add_speaker("S01")

bundle_id = proj.add_bundle(
    "speaker_01_take_2",
    Path("rec02.wav"),
    speaker_id=speaker_id,
    extra='{"elicitation": "rainbow_passage", "take": 2}',
)

Large recordings

Loading a bundle decodes the whole file into memory, so a single very long recording (hours) can be slow — or exceed RAM on a smaller machine. You can probe a file's size from its header alone first, with no samples decoded:

info = sadda.probe_wav(Path("interview_3h.wav"))
print(info.duration_seconds, info.decoded_bytes)  # decoded_bytes ≈ the RAM a full load costs

If a file is too large to work with comfortably, split it into contiguous pieces — each registered as its own bundle (<prefix>_001, _002, …). The split streams the source, so memory stays flat regardless of length:

ids = proj.add_bundle_split(
    "interview", Path("interview_3h.wav"), chunk_seconds=600  # 10-minute pieces
)

In the desktop app this is automatic: File → Add Bundle… probes the file first, and if it's large enough to be risky it offers to split it (or add it as-is) before loading. (probe_wav is provisional and warns once on first use.)

Run pitch and formants

The DSP surface (sadda.dsp.*) is functional — every function takes an Audio (or, for some, NumPy float32 arrays plus a sample rate) and returns NumPy or dataclass results. No corpus dependency:

audio = proj.load_audio(bundle_id)

times, freqs, voicing = sadda.dsp.voiced_pitch(
    audio,
    frame_size_seconds=0.030,
    hop_size_seconds=0.010,
    min_freq_hz=75.0,
    max_freq_hz=500.0,
)

formants = sadda.dsp.formants(audio, n_formants=4)

Clinical measures

sadda.clinical.* adds voice-quality measures — jitter, shimmer, HNR, CPP / CPPS, H1–H2, GNE, and the AVQI / ABI composite indices. Every measure is a pure function over an Audio:

perturbation = sadda.clinical.perturbation(audio)
print(f"jitter local: {perturbation.jitter_local:.4f}")
print(f"shimmer local dB: {perturbation.shimmer_local_db:.3f}")

hnr_db  = sadda.clinical.hnr(audio)
cpps_db = sadda.clinical.cpps(audio)

All clinical measures are research-use only. They live in their own stable_clinical tier — the API commitment is the same as Stable, but the tier name flags the clinical-research caveat (see the stability tiers table).

Reference distributions

sadda.refdist.* lets you compare a measurement against normative ranges, target zones, or observed corpora. The bundled set ships with the wheel; the desktop app's View menu has an "Install bundled reference data" command that seeds the per-user cache, and the same distributions are available from Python:

sadda.refdist.install("refdist-bundled/placeholder-amE-vowels")
vowels = sadda.refdist.get("placeholder-amE-vowels", "0.1.0")
print(vowels.summary("F1").mean, vowels.summary("F1").sd)

ML inference (voice activity, embeddings)

With sadda[ml] installed, sadda.ml.vad runs the bundled Silero VAD over an Audio and returns per-window speech probabilities:

times, probs = sadda.ml.vad(audio)
for start, end in sadda.ml.speech_segments(audio, threshold=0.5):
    print(f"speech {start:.2f}–{end:.2f}s")

sadda.ml.load_model("hf://<org>/<repo>/<file>") (download-enabled builds only) lets you pull wav2vec2 / Whisper-style ONNX models and extract embeddings as a B3 continuous-vector tier — see sadda.ml for the full surface.

Import existing annotations

Open Praat TextGrids or ELAN .eaf files directly into a bundle:

proj.import_textgrid(Path("phones.TextGrid"), bundle_id)
proj.import_eaf(Path("annotations.eaf"), bundle_id)

Round-trip semantics (what's preserved, what's lost) are documented under Round-trip lossiness.

Query annotations as a DataFrame

Every tier can be pulled into a Polars DataFrame. proj.query takes the integer tier id returned by add_tier(...) or import_textgrid(...):

import polars as pl

[phones_tier] = proj.import_textgrid(Path("phones.TextGrid"), bundle_id)
df = proj.query(phones_tier)
print(df.head())
# shape: (2, 8)
# ┌─────┬─────────┬───────────────┬─────────────┬──────────────────┬───────┬──────────────────────┬───────┐
# │ id  ┆ tier_id ┆ start_seconds ┆ end_seconds ┆ duration_seconds ┆ label ┆ parent_annotation_id ┆ extra │
# ├─────┼─────────┼───────────────┼─────────────┼──────────────────┼───────┼──────────────────────┼───────┤
# │ 1   ┆ 1       ┆ 0.0           ┆ 0.12        ┆ 0.12             ┆ h     ┆ null                 ┆ null  │
# │ 2   ┆ 1       ┆ 0.12          ┆ 0.27        ┆ 0.15             ┆ ɛ     ┆ null                 ┆ null  │
# └─────┴─────────┴───────────────┴─────────────┴──────────────────┴───────┴──────────────────────┴───────┘

Record an analysis recipe

A recipe is a reproducibility primitive — the operations you run inside a with sadda.recipe.record(...): block are linked to a named record in the corpus, and a runnable .py script is emitted to <project>/recipes/<name>.py:

with sadda.recipe.record(proj, name="phone_import_v1"):
    proj.import_textgrid(Path("phones.TextGrid"), bundle_id)
    proj.import_eaf(Path("annotations.eaf"), bundle_id)

# Re-run later:
#   python vowels/recipes/phone_import_v1.py

Recipes capture the calls that already produce processing_run rows in the corpus: TextGrid / EAF imports and live recordings in 0.1.0. Pure-DSP calls are reproducible from your own script.

Live recording

To record from a microphone:

session = sadda.live.start_session(proj, name="practice_take_1",
                                   sample_rate=44100, channels=1)

@session.on_meter
def show(peak, rms, rms_db, t):
    print(f"{t:.2f}s  rms={rms_db:+.1f} dB-FS")

session.start()
import time; time.sleep(5.0)
session.stop()

bundle_id = session.commit(proj)

The live surface includes on_meter, on_pitch, on_intensity, on_formants subscribers — see sadda.live for the full surface.

Where to go next

• API reference for every public class and function.
• Round-trip lossiness when you need to know exactly what survives an import/export round-trip.
• The DEVLOG.md in the repo for the design history.
